Quite Universal Circuit Simulator (Qucs) is an open-source electronics circuit simulator software released under GPL. It gives you the ability to set up a circuit with a graphical user interface and simulate the large-signal, small-signal and noise behaviour of the circuit. Pure digital simulations are also supported using VHDL and/or Verilog.
Qucs supports a growing list of analog and digital components as well as SPICE sub-circuits. It is intended to be much simpler to use and handle than other circuit simulators like gEDA or PSPICE.
Nombre | Qucs |
Versión actual | 0.0.18-1 |
Plataforma | Linux |
Licencia | GPL |
Web: | http://qucs.sourceforge.net/ |
Manuales | http://qucs.sourceforge.net/docs.html |
Software privativo relacionado | Orcad, Eagle, PSIM |
